SPECIFICATIONS
Product Code: 13303-0302
IR Resolution: 320 × 240 pixels
Accuracy: ±2°C or ±2% of reading, for ambient temperature 10°C to 35°C and object temperature above 0°C
Minimum Focus Distance: 0.36 m
f-number: 1.4
Image Modes: Thermal MSX, Thermal, Picture-in-Picture, Thermal blending, Digital camera
Detector Type: Uncooled microbolometer
Field of view (FOV): 33°
Object Temperature Range: –20°C to 550°C  in two ranges
Operating Temperature Range: –15°C to 40°C
Storage Temperature Range: –40°C to 70°C
Thermal Sensitivity/NETD: <0.04°C / <40 mK
Spectral Range: 7.5–13 µm
Spatial resolution (IFOV): 1.8 mrad
Digital Camera Resolution: 5 MP
Display: 3.5 in, 640 × 480 color LCD
Image Frequency: 9 Hz
Drop Test: 2 m
Encapsulation: IP54
Power: Rechargeable 3.6 V Li ion battery
Camera size (L x W x H): 244 mm × 95 mm × 140 mm
Packaging Size: 385 mm × 165 mm × 315 mm
Weight incl battery: 0.590 kg

• Industrial inspections of electrical and mechanical equipment
• Condition monitoring and preventive maintenance of degrading equipment before failure
• Building inspections to ensure energy efficiency
